Cfgindustrial 1.4 Ton Mini Skid Steer Loader with Kubota D1105 Engine | TK35

The TK35 is a versatile 1.4 ton class skid steer loader featuring an open cab design for easy operator access and excellent visibility. Powered by a rugged Kubota diesel engine, this machine is built for durability, maneuverability, and reliable performance across a wide range of jobs.

KEY FEATURES:

• 1.4 ton (= 3,000 lb) rated operating capacity

• Kubota diesel engine known for efficiency and longevity
• Open cabin (roll-over protection) for excellent operator sight lines
• Universal quick-attach plate for compatibility with standard attachments
• Robust hydraulic system to drive attachments effectively
• Heavy-duty steel frame construction for durability


BENEFITS:

• ldeal balance of size and power for tight job sites

• Easy access to engine and maintenance points
• Versatility through compatibility with buckets, augers, grapples, trenchers, hammers, etc
• Cost-effective for contractors needing a compact utility loader
• Lower overall weight simplifies transport and reduces ground disturbance


APPLICATIONS:

• General construction, landscaping, material handling

• Utility work, site prep, trenching, backfill

• Farms, nurseries, and property maintenance

DIMENSION:

• Operating Weight: 1.5 Ton (3,307 lb)

• Overall Length: 2,911 mm (114.5 in)

• Overall Width: 912 mm (36 in)

• Overall Height: 910 mm (36 in)

• Bucket Width: 914 mm (36 in)

• Bucket Capacity: 0.16 m³ (0.2 yd³)

• Tracks Size: 200*72*45 (W*P*L)

WORKING RANGE:

• Max Working Height: 3,686 mm (145 in)
• Max Unloading Height: 1,933 mm (76 in)
• Max Lifting Force: 380 kg (838 lb)
• Max Travel Speed: 9 km/h (5.6 mph)

FEATURES:

• Kubota Diesel Engine

ENGINE:

• Brand / Model: Kubota D1105

• Fuel Type: Diesel

• Max Power: 18.2 kW (24.4 HP)

• Displacement: 1,100 cc

• Fuel Tank: 28 L (7.4 gal)
• Hydraulic Tank Capacity: 40 L (10.5 gal)
